Continuous moving bed equipment is a completely innovative separatio≠n technology, and is different from the traditional f↓ixed bed, pulse bed, simulated moving bed and other processes. It is based $on the traditional fixed bed resin adsorption and ion exchange and is deve←loped by combining continuous counter-current system technology.

Continuous moving bed equipment can be used to separate, refine and recycl★e a variety of industrial water and other solutions of sp>ecific effective substances and harmful substances. This system can use the traditional adsor bent (such as ion exchange resin, activated carbon and synthetic adsorbent, etc.).↓

Working theory of continuous moving bed equipment

The continuous moving bed is composed of a disc with a♣ plurality of resin columns (16, 20, 30 columns) and ←a perforated dispensing valve. Through the rotation o≥f the disc and the valve port of the conversion, the separation column finish a p↔rocess cycle of adsorption, washing, desorption, and regener↕ation. And in the continuous separation system, all the‍ process of ion separation is carried out simultaneously. In co♥ntrast, the fixed bed ion separation system only operates all steps in a batch process for a peri≤od of time.

System Features:

Product ingredients and concentrations remain stable;λ

Can be flexible to change the production process as a result of multi-×column system;

Automatic, programmed operation control. Stable enough and can avoid manual o♥peration errors

Compact and easy to install in any location. Easy to match the old productπion process and equipment;

Can remove or separate substances with different characteristics si↓multaneously, which simplifies the process;

Resin consumption is significantly reduced by 50-90↑%, and the maximum amount of washing water can save 50-70%, so does ch₽emicals, eluents consumption, which reduces investment cost.

Applications

Pharmaceutical industry (antibiotics, vitamins)

Fine Chemicals and Biotechnology (Separation of Chiral Substance)

Food industry (sugar softening, de-mineralization of glucose, bleachin♦g of syrup, purification of fructose syrup)

Hydrometallurgical industry (metal recycling)

Water treatment (wastewater treatment, pure water preparation)
